On this page
Highlights
- Print speeds of up to 12ips with 300dpi resolution.
- Print width of up to 104mm.
- FBPL-EZD (EPL2, ZPL2, DPL) printer command languages supported.
- High capacity 600m thermal transfer ribbon means fewer media changes.
- Connect easily with USB, USB Host, Serial, Ethernet and optional dual wireless interface (WiFi and Bluetooth).
Specifications
| Manufacturer reference | TJ-4522TN |
|---|---|
| EAN code | 4977766804660 |
| Type | Industrial label printer |
| Technology | Direct thermal / Thermal transfer |
| Maximum print width | 10.4 cm |
| Maximum label width | 11.4 cm |
| Print speed | 305 mm/sec |
| Resolution | 300 x 300 DPI |
| USB | Yes |
| Ethernet | Yes |
| Serial port | 1 |
| Mobile systems | Android, iOS |
| Windows | Windows 10, Windows 7, Windows 8.1 |
| Mac | Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra... |
| Fonts | 8 |
| Built-in barcodes | AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix... |
| Languages | DPL, EPL2, ZPL II |
| Memory | 256 MB |
| Maximum roll diameter | 20.3 cm |
| Operating temperature | 0 - 40 °C |
| Dimensions (W x D x H) | 400 x 635 x 545 mm |
| Weight | 19.4 k g |
| Origin | Taiwan |
Consumables, maintenance parts and accessories
Use
Brother TJ-4522TN label printer for retail, logistics and heavy industry: rolls up to 114 mm, direct thermal and thermal transfer, sustained throughput.
Cas d'usage : étiquettes de colis et de palettes, étiquettes de prix et de rayon, traçabilité, tickets, bracelets et étiquettes de laboratoire. Pilotage depuis un logiciel métier, un ERP ou un terminal (langages ZPL, ESC/P, P-touch Template). Connexion : USB, Ethernet. Les consommables (rubans, rouleaux) sont listés plus haut ; le prix par étiquette dépend surtout du support choisi.
The TJ-4522TN is self-contained and complete for its category. For higher volumes or other options, see Brother label printers.
Frequently asked questions
Which consumables does the TJ-4522TN use?
See the list of compatible products above or the Brother manufacturer sheet.
Can the TJ-4522TN be connected to a network?
Yes: USB, Ethernet.
Where can I find drivers and the manual?
On our Brother support page: drivers, user guide, software and FAQ for the TJ-4522TN, by country.
